INDUSTRIAL BALANCING MACHINES

simple design solution to minimize the risk of failure
unbalance evaluation with an accuracy of 0.1 gmm or 0.01 g according to the selected evaluation unit
determining the angular position of the unbalance with an accuracy of 0,1 °
intuitive operation
balancing is facilitated by data on the required drilling depth according to the tool used and the calculation of the split weights in the case of a rotor with spokes
the electrically operated brake supports automatic stopping at the unbalance position and rotor balancing directly on the spindle
rotor balance parameters (dimensions; balance limit; rotation speed) can be stored in the rotor bank
possibility to export balancing protocol directly from the machine to USB or to specified network storage
balance rate and independence rate balancing planes are determined according to ISO 2593
easy to change fixtures
low floor space requirements
simple installation
low purchase costy
low maintenance costs
power supply: net 230V; max. 1600W
Czech machine produced under our license
